Keysight N2751A

Product Highlights

• Dynamic range: ± 5 V or 10 Vpp (at 10:1), ± 1 V or 2 Vpp (at 2:1)
• DC offset range: ± 15 V
• Maximum input voltage: 30 V DC + peak AC
• Differential input R: 200 kΩ
• Single-ended input R: 100 kΩ
• Common mode input R: 50 kΩ
• Input C: 700 fF (with browser)
• Comes standard with solder-in, socketed and browser tips (two each)
• Replacement parts: N2776A Differential browser tips (including qty 3), N2777A InfiniiMode solder-in tips (including qty 3), and N2778A InfiniiMode socketed tips (including qty 3)
• Order N4822A socketed tip for use with USB/Ethernet application fixtures (not included in the standard probe kit)
